Vililong Product Display
VES Stainless Steel Freestanding Enclosure
VES series 5-fold structural frame freestanding enclosure is a side panel can not be disassembled, the sealing effect is better, the protection level is relatively high, the cost performance is also high, can only be used independently, can not be combined.
Features
- Made of Sus304/Sus316 stainless steel plate by bending and welding
- 5-fold structural frame
- Three-section flexibleinlet/outlet line device
- The door are reinforced with square tubes
- Modular holes with a spacing of 25mm on the frame ensures flexibility and universality of installation
- The surface is treated with epoxy resin electrostatic spraying
- Door panel PU sealing strip to prevent dust and rain from penetrating
- Equipped with removable mounting plate
- IP55 protection rating
Support
- Custom sizes
- Material/Material thickness
- Lock/Hinge/Stiffener
- Different powder coating colors and finishes
- Custom Logo/Text
- Pre-cut holes for For wiring, ventilation, and component integration
VES Stainless Steel Freestanding Enclosure
*Some content and parameters are for reference only. Our company can adjust performance and customize processing according to customer needs.
Technical Data
| Material Options | Steel/Stainless Steel |
| Sizes | Custom sizes available |
| Ingress Protection (IP) Rating | IP65 |
| Temperature Range | -20～C to +60～C |
| NEMA Rating | NEMA 1, NEMA 3R, NEMA 4X (depending on model) |
| Mounting Type | Freestanding (floor-mounted) |
| Standard Configuration | Door Plate Box Body Sealingstrip Grounding Set Mounting Plate Door Lock |
Regular size
| Size (W*H*D) |
Materials | Surface Reatment | Thicknes(mm) Box body/Door Plate/Mounting Plate |
|---|---|---|---|
| 600*1200*400 | Sus304/316 | Wire Drawing | 1.2/1.5/2.0 |
| 700*1500*400 | Sus304/316 | Wire Drawing | 1.2/1.5/2.0 |
| 700*1700*400 | Sus304/316 | Wire Drawing | 1.5/2.0/2.0 |
| 800*1800*400 | Sus304/316 | Wire Drawing | 1.5/2.0/2.0 |
| 800*1800*600 | Sus304/316 | Wire Drawing | 1.5/2.0/2.0 |
| 800*2000*600 | Sus304/316 | Wire Drawing | 1.5/2.0/2.0 |
Professional Electrical Enclosure Manufacturer
Wenzhou Vililong Technology Co., Ltd.
We are a professional manufacturer specializing in high-quality Electrical enclosures, offering a wide range of solutions for electrical and industrial applications. Our products, including Electrical Distribution Boxes&Cabinets, as well as customized enclosures and Rittal Alternatives, are engineered using advanced sheet metal processing technologies (such as laser cutting,CNC bending, welding robots, etcto) ensure precision, durability, and superior performance.
0Years experience
Electrical Enclosure
Manufacturing
Manufacturing
0Employees
R&D, design, production
Technical team
Technical team
0Equipments
Automated production equipment
0sqm
Modern production and manufacturing base
Laser Cutting Machine
It can be used for cutting a variety of metal materials and has the advantages of fast processing speed, fine workmanship, strong adaptability and high flexibility..
CNC Bending Machine
Precise and accurate CNC bending equipment. Customized design to meet your multiple bending needs.
Bending Machine
Large tonnage bending machine to meet customer requirements for large box.
Welding Robot
Panasonic welding robots provide you with reliable peace of mind and assured products
Professional Drawing
Professional sheet metal engineers to meet customer customization needs.
Quantity Production
5000 square meters of plant and professional production equipment and personnel, to meet the mass production of customers.
Certification
CE
IP65
ISO9001
FAQ-ES Stainless Steel Freestanding Cabinet
What is an ES Freestanding Cabinet?
An ES Freestanding Cabinet is a self-standing industrial enclosure designed to protect electrical, automation, and control equipment. It offers durability, security, and flexibility, making it ideal for various industrial applications.
Why Choose a Stainless Steel ES Cabinet?
Stainless steel provides excellent resistance to corrosion, chemicals, and harsh environments, ensuring long-term performance in demanding industries such as food processing, marine, and industrial automation.
What Are the Key Features of This Cabinet?
- High-Strength Frame – Reinforced design for maximum durability.
- IP55 – Resistant to dust and water ingress.
- Secure Locking System – Prevents unauthorized access.
- Customizable Design – Available in various sizes and configurations.
- Pre-Drilled Mounting Options – Easy installation for electrical components.
What Industries Use ES Freestanding Cabinets?
Our stainless steel ES Cabinets are widely used in:
- Industrial Automation & Control Systems
- Power Distribution & Electrical Equipment
- Food & Beverage Processing Plants
- Marine & Offshore Environments
- Chemical & Pharmaceutical Industries
Can This Cabinet Be Customized?
Yes! We offer custom sizes, ventilation options, cable entry configurations, and locking mechanisms to meet your specific needs.
How does SUS304 compare to SUS316?
| Property | SUS304 | SUS316 |
|---|---|---|
| Corrosion Resistance | Good | Excellent (better for marine & chemical environments) |
| Molybdenum (Mo) Content | 0% | 2-3% |
| Strength & Durability | High | Slightly higher |
| Cost | Lower | ~20-30% higher |
| Best For | General industrial enclosures | Harsh environments (marine, chemicals, saltwater) |
High-Strength ES Freestanding Cabinet – The Perfect Alternative to Rittal
Our ES Cabinet is designed as a high-quality alternative to Rittal ES cabinets, offering superior strength, protection, and flexibility for industrial applications. Built with an advanced five-fold profile frame, our enclosures provide exceptional structural integrity, increased load capacity, and enhanced installation flexibility—making them ideal for housing electrical, automation, and power distribution systems.
Key Features of Our ES Freestanding Cabinet
✅ Material Options: Stainless Steel 304/316 or Powder-Coated Mild Steel
✅ IP55 Protection: Dustproof & Waterproof for harsh environments
✅ Durable Construction: Strong sheet metal housing for industrial use
✅ Customizable Designs: Custom sizes, cutouts, locks, and branding available
✅ Competitive Pricing: A cost-effective alternative to major brands
Rittal ES Cabinet vs. Our Alternative – Side-by-Side Comparison
| Material Options | Steel/Stainless Steel |
| Sizes | Custom sizes available |
| Ingress Protection (IP) Rating | IP65 |
| Temperature Range | -20～C to +60～C |
| NEMA Rating | NEMA 1, NEMA 3R, NEMA 4X (depending on model) |
| Mounting Type | Freestanding (floor-mounted) |
| Standard Configuration | Door Plate Box Body Sealingstrip Grounding Set Mounting Plate Door Lock |
Applications:
Industrial Automation & Process Control
Power Distribution & Electrical Panels
Data Centers & Telecommunications
Renewable Energy Systems
Customization Options Available
We understand that every project is unique. That’s why we offer customizable ES Freestanding Enclosures to meet your exact needs:
🔧 Custom dimensions & mounting options
🔧 Custom holes for cable entry & ventilation
🔧 Custom powder coating and branding (logo engraving available)
🔧 Special lock and security options
Why Choose Our ES Five-folds profies Cabinet Alternative?
Our high-strength, five-fold profile ES Cabinets provide a cost-effective, durable, and fully customizable alternative to Rittal enclosures. Contact us today for a custom quote and take advantage of our global shipping options!
Flexible Sheet Metal Fabrication Solutions Available
Professional Electrical Cabinet Manufacturer
Brings Excellent Services
How Can We Help Your Business?
What’s your company main products?
The main business is to provide customers with custom enclousure services, we also sell some General Boxes.
How about the price of the product?
We are a manufacturer, we mainly provide customized services for our customers, and we believe that our prices have enough advantages.
What does the enclosure customization service contain?
Box Sizes,Box Colors,Door Types,Gland Plates,Specific Cutouts,Moutning Plates,Protective Covers,Standing Types,Windows,Thickness,Accessories.
Can we get the sample? Is it free?
Yes, we could offer the general box sample for free charge,but need you pay the express. The freight depends on weight, packing size and your country or province region, etc.
What’s about MOQ?
First order MOQ=1pcs.
How can I get product catalogs?
You can get the catalogs by contacting us.
How to order our product?
1.Please tell us the model and quantity and other request you need.
2.We make the PI for you.
3.After you confirm the PI, we arrange the order for you after receiving your payment.
4.After the goods finished, we send the goods out to you and tell you the tracking number.
5.We will track your goods until you receive the goods.
How about the after-sale service?
If you meet any problems after sales, pis contact us freely, we’ll help solving the problems within 24 hours.
What’s the payment term?
100% T/T (large order, accept 30% T/T prepay 70% balance before shipping), Western Union, Paypal.
